HAWKE 710 CABLE GLANDS
The 710 Cable Gland is a Division and Zone approved barrier cable gland for North American applications. UL approved for use in Increased Safety (Exe), Flameproof (Exd) and Dust (Ext) Zone protection concepts, along with North American C1 Div 1 Explosion Proof. UL listed for use with the following cable types: TC-ER-HL, TC-ER, PLTC, PLTC-ER, ITC, ITC-HL & ITC-ER. The gland features the worlds only NEC compliant fully inspectable transparent elastomeric compound chamber The gland also provides an elastomeric seal on the cable inner sheath, and a low smoke, zero halogen IP and retention seal onto the cable outer sheath.
- metallic body construction
- Fully Inspectable Elastomeric Compound Chamber
- Available with either ExPress (liquid resin) or QSP (2-part hand mix compound), both with a cure time of 30 minutes
- Patented Cable Gland Tightening Guide - Helps prevent damage caused by over tightening
- Unique Rear Seal - Offering ultimate sealing over an extremely wide cable acceptance range
- Inspectable Deluge Seal - Offering IP66, IP67, IP68 & IP69 Ingress Protection
- Available with metric or NPT entry threadforms
General Application：
Product details：
Suitable for use in North America Division 1, Division 2, Zone 1, Zone 21, Zone 2 and Zone 22
Ingress Protection：
IP66, IP67, IP68* (30 metres for 7 days; special instructions apply), IP69 to IEC/EN 60529
Type 4X，Deluge Protection to DTS01
Material：Manufactured in Brass, Nickel Plated Brass or 316L Stainless Steel
Operating Temperature：-50°C to +80 °C
Series：Cable Glands for North America
| Hawke防爆格兰 |
Hawke防爆格兰（710系列） |
Hawke防爆格兰（711系列） |
| Hawke防爆格兰 |
710/OS/M20 |
Hawke防爆格兰 |
| Hawke防爆格兰 |
710/OS/1/2"NPT |
Hawke cable gland |
| Hawke防爆格兰 |
710/O/M20 |
Hawke防爆格兰 |
| Hawke防爆格兰 |
710/O/1/2"NPT |
Hawke cable gland |
| Hawke防爆格兰 |
710/A/M20 |
711/A/M20 |
| Hawke防爆格兰 |
710/A/1/2"NPT |
711/A/1/2"NPT |
| Hawke防爆格兰 |
710/B/M25 |
711/B/M25 |
| Hawke防爆格兰 |
710/B/3/4"NPT |
711/B/3/4"NPT |
| Hawke防爆格兰 |
710/C/M32 |
711/C/M32 |
| Hawke防爆格兰 |
710/C/1"NPT |
711/C/1"NPT |
| Hawke防爆格兰 |
710/C2/M40 |
711/C2/M40 |
| Hawke防爆格兰 |
710/C2/1.1/4"NPT |
711/C2/1.1/4"NPT |
| Hawke防爆格兰 |
710/D/M50 |
711/D/M50 |
| Hawke防爆格兰 |
710/D/2"NPT |
711/D/2"NPT |
| Hawke防爆格兰 |
710/E/M63 |
711/E/M63 |
| Hawke防爆格兰 |
710/E/2.1/2"NPT |
711/E/2.1/2"NPT |
| Hawke防爆格兰 |
710/F/M75 |
711/F/M75 |
| Hawke防爆格兰 |
710/F/3"NPT |
711/F/3"NPT |
| Hawke防爆格兰 |
710/H/M90 |
711/H/M90 |
| Hawke防爆格兰 |
710/H/3.1/2"NPT |
711/H/3.1/2"NPT |
| Hawke代理分销 |
上海颐品自动化科技有限公司 |
Hawke cable gland |
Why should you choose Hawke Cable Glands?
Hawke Internatio
nal Cable Glands are the obvious choice for those who demand quality, reliability and above all, safety.All Hawke products are designed and manufactured under a quality system not o
nly complying with ISO 9001 standards but also with the latest internatio
nal standards. All of our products are certified globally by ATEX, IECEx, INMETRO and more. Rigorous in-house and third party testing ensures that all our products always exceed expectations.Every Hawke Cable Gland is manufactured to survive in the world’s toughest environments. They can be used in general industrial applications, increased safety areas or in areas wher
e flameproof, explosion proof and deluge resistant features are required. Whatever your requirements, Hawke has a globally certified Gland to fit them perfectly.
